उत्पाद विवरण:
|
| वज़न: | 25 किलोग्राम | सामग्री: | कार्बुराइज्ड स्टील |
|---|---|---|---|
| प्रसंस्करण प्रकार: | फोर्जिंग | व्यास सीमा: | 3.5 - 12 इंच (90मिमी-305मिमी) |
| चेहरे का आकार: | समतल, उत्तल, अवतल | बटन प्रकार: | गोलाकार, परवलयिक, बैलिस्टिक |
| वायु नली: | 2, 3, 4 | गेज बटन: | 6×φ14, 7×φ13, 7×φ14, 8×φ14, 7×φ16, 7×φ18, 8×φ18, 9×φ18, 10×φ18, 11×φ18, 12×φ18 |
| सामने के बटन: | 5×φ13, 6×φ13, 6×φ14, 7×φ14, 8×φ14, 8×φ16, 9×φ16, 12×φ16, 17×φ16, 29×φ16 | भाग संख्याएँ: | एम40-105, एम40-110, एम40-115, एम40-120, एम40-127, एम50-130, एम50-140, एम50-146, एम50-152, एम50-165, |
| रॉक कठोरता: | 200 एमपीए से 260 एमपीए | बिट दीया (मिमी): | 105, 110, 115, 120, 127, 133, 140, 146, 152, 165, 178, 190, 203, 195, 216, 254, 305 |
| बिट व्यास (इंच): | 4 1/8", 4 1/4", 4 1/2", 4 3/4", 5", 5 1/4", 5 1/2", 5 3/4", | सम्पीडक क्षमता: | 200 एमपीए से 260 एमपीए |
| ड्रिलिंग गहराई: | कोई सीमा नहीं | ||
| प्रमुखता देना: | M30 M40 M50 M60 M80 Shank DTH Drill Bits,3.5 - 12 Inch Down The Hole Drill Bits,Carburized Steel Button Bits |
||
DTH hammers and bits are widely used in underground mining, quarries, hydraulic and hydro-power engineering, water well drilling, mineral exploration, anchoring hole drilling, geothermal engineering, subway excavation, and other civil engineering applications. They offer advantages including high flatness, smooth hole walls, high rigidity of drill rod and hammer, independent high axial thrust, unlimited drilling depth, low device costs, and easy maintenance.
| Mission Bits | Bit Dia (mm) | Bit Dia (inch) | Air Hose | Gauge Buttons | Front Buttons | Part No |
|---|---|---|---|---|---|---|
| Mission40 | 105 | 4 1/8" | 2 | 6×φ14 | 5×φ13 | M40-105 |
| 110 | 4 1/4" | 2 | 7×φ13 | 6×φ13 | M40-110 | |
| 115 | 4 1/2" | 2 | 7×φ14 | 6×φ13 | M40-115 | |
| 120 | 4 3/4" | 2 | 8×φ14 | 6×φ14 | M40-120 | |
| 127 | 5" | 2 | 8×φ14 | 7×φ14 | M40-127 | |
| Mission50 | 133 | 5 1/4" | 2 | 7×φ16 | 6×φ14 | M50-130 |
| 140 | 5 1/2" | 2 | 7×φ18 | 7×φ14 | M50-140 | |
| 146 | 5 3/4" | 2 | 8×φ18 | 7×φ14 | M50-146 | |
| 152 | 6" | 2 | 8×φ18 | 8×φ14 | M50-152 | |
| 165 | 6 1/2" | 2 | 8×φ18 | 8×φ16 | M50-165 | |
| Mission60 | 152 | 6" | 2 | 8×φ16 | 8×φ16 | M60-152 |
| 165 | 6 1/2" | 2 | 8×φ18 | 8×φ16 | M60-165 | |
| 178 | 7" | 2 | 8×φ18 | 8×φ18 | M60-178 | |
| 190 | 7 1/2" | 3 | 9×φ18 | 9×φ16 | M60-190 | |
| 203 | 8" | 3 | 9×φ18 | 9×φ18 | M60-203 | |
| Mission80 | 195 | 7 11/16" | 3 | 9×φ18 | 9×φ16 | M80-195 |
| 203 | 8" | 3 | 9×φ18 | 9×φ18 | M80-203 | |
| 216 | 8 1/2" | 2 | 10×φ18 | 12×φ16 | M80-216 | |
| 254 | 10" | 3 | 11×φ18 | 17×φ16 | M80-254 | |
| 305 | 12" | 4 | 12×φ18 | 29×φ16 | M80-305 |
Delivery options: By sea, by air, or by express
