उत्पाद विवरण:
|
| वज़न: | 29 किग्रा | सामग्री: | कार्बन स्टील |
|---|---|---|---|
| प्रसंस्करण प्रकार: | फोर्जिंग | आकार: | 3 इंच |
| बहरी घेरा: | 81 मिमी | लंबाई: | 1063 मिमी |
| बटन आकार: | बैलिस्टिक/सेमी-बैलिस्टिक/गोलाकार | बिट टांग: | एसआरसी531 |
| होल रेंज: | φ84- φ100 | कनेक्शन धागा: | 3" रिमोट |
| कार्य का दबाव: | 1.0MPa-3.0MPa | हवाई खपत: | 7 m @ min @ 1.7 MPa |
| हवाई खपत: | 10 m @ min @ 2.4 MPa | हवाई खपत: | 14 m @ min @ 3.0 MPa |
| लंबाई (कम बिट): | 1069 मिमी | ||
| प्रमुखता देना: | SRC531 RC Hammer,3inch Reverse Circulation Hammer,81mm Down The Hole Hammer |
||
Reverse circulation drilling efficiently collects samples by transporting them through hollow pipes, preventing contamination from surface materials. This method is particularly valuable for maintaining sample integrity in mining and well drilling applications.
| Length (less bit) | 1069mm |
| Weight (less bit) | 29.0kg |
| External diameter | φ81mm |
| Bit shank | SRC531 |
| Hole range | φ84-φ100 |
| Connection thread | 3" Remet |
| Working pressure | 1.0Mpa-3.0Mpa |
| Air consumption (1.7 Mpa) | 7 m³/min |
| Air consumption (2.4 Mpa) | 10 m³/min |
| Air consumption (3.0 Mpa) | 14 m³/min |
Standard delivery time: 15-25 days. Express delivery (3-5 days) available when items are in stock.
Shipping options: By Air, By Sea, or By express.
Packaging: Ply-wooden cases with pallet.
